WICTEC 50 EL
WICTEC 50 EL is a unitised version of the WICTEC 50 stick system. This range combines the advantages of the stick system structure with the assembly benefits of unitised curtain walling and creates extremely narrow sight lines of only 50 or 65 mm.
The external profiles are mitre cut, achieving a particularly elegant “picture frame” appearance. Where there are stringent requirements pertaining to thermal insulation, WICTEC 50 EL offers the appropriate solution.
Documentation
Characteristics
System test results / CE product pass in accordance with DIN EN 13830
Air permeability
Water tightness
Resistance to wind load
Impact resistance
Quality assurance
Environmental management
Class AE
RE 1200
2000 / –3200 Pa, security 3000 / –4800 Pa
Class E5 / I5
Certified according to ISO 9001:2008
Certified according to ISO 14001
Technical performance
System width
Profile depth
Thermal insulation
Infill thickness
Unit sizes
50 mm for integral fenestration and 65 mm for coupled frames
195 mm to 213 mm
Uf up to 1.4 W/(m²K) horizontally and Uf up to 1.5 W/(m²K) vertically
up to 44 mm
(w x h) up to 3000 mm x 3500 mm, up to 1500 mm width without integrated mullions
System technology
- WICTEC 50 EL is a basic unitised system and can be adapted individually to meet specific project requirements
- The complete units are produced in the workshop, avoiding the influence of weather conditions and assuring a constantly high level of quality
- Fast, efficient and projectable assembly on site
- Aluminium profiles using mullion-transom technology, with insulating profiles that provide a high level of thermal insulation
- Narrow sight lines for maximum transparency
- Mullions and transoms have the same profile depth
- Efficient thermal performance, up to Uf = 1.4 W/(m²K)
- Reliable corner connection with systemised brackets
- Fast and easy installation on site using a dedicated anchor system
