Passive house does not require an active heating system and therefore relies heavily on the thermal insulation and air-tightness of the façade. Based on the standard series, WICTEC 50 HI is certified for aluminium/glass façades suitable for passive houses at minimal additional cost. The thermal insulation exceeds the benchmark requirements of passive-house, with a Uf value of 0.65 W/(m²K) thanks to easy-to-install special thermal break profiles in combination with triple glazing.


System test results / CE product pass in accordance with DIN EN 13830

Air permeability
Water tightness
Resistance to wind load
Sound insulation
Impact resistance
Burglar resistance
Quality assurance
Environmental management
Class AE
RE 1200
2000 / –3200 Pa, security 3000 / –4800 Pa
Rw (C;Ctr) = 47 (–1; –4) dB
Class E5 / I5
Certified according to ISO 9001:2008
Certified according to ISO 14001

Technical performance

System width
Basic system
Thermal insulation
Infill thickness
Glass weight
Polygon façade
50 mm
Uf = 0.65 W/(m²K)
up to 63 mm
up to 6.0 kN
up to 5°

System technology

  • Extension to WICTEC 50 with optimised thermal insulation
  • Certified by the ift Rosenheim as a passive house component according to the ift guidance paper RI WA 15/1, with a Ucw value of 0.7 W/(m²K)
  • Triple glazing construction suitable for passive houses, infill thicknesses up to 63 mm
  • Thermally enhanced isolator profiles for subsequent installation
  • System construction identical to standard WICTEC 50
  • Ideal for vertical and polygon façades, sloped glazing and spatial structures
  • Individual design possibilities, thanks to a wide range of aesthetic profiles
  • Reliable glass load transfer (up to 6.0 kN), with improved transom-joint technology
  • Overlapping and secure drainage at the cruciform, without mechanical mullion processing, ensures tried-and-tested impermeability
  • Consistent internal gasket appearance
  • Wide selection of structural profiles, with optional integral reinforcements, ensuring optimal performance
