Glasshouse system VARIOLUX

Learn more

GLASSHOUSE SYSTEM VARIOLUX

Our patented glasshouse system combines maximum design freedom with energy efficiency and sustainability. Whether it’s an open roof structure, a fully glazed building envelope, or the integration of photovoltaic panels – our experts and partners support your project from the initial idea through to completion.
picture slider
picture slider
picture slider

Documentation

Brochure VARIOLUX - EN

(17 MB, pdf)

Characteristics

System test results / CE product pass in accordance with EN DIN EN 13830 / Building authority approvals

Air permeability
Water tightness
Resistance to wind load
Impact resistance
Up to AE (750 Pa)
Up to R7 (600 Pa)
Up to 1,6 kN/m²
Class I5/E5

Technical performance

System width
Profile depth
Thermal insulation
Infill thickness
Roof pitch
42mm to 50/52 mm
Wall profiles: 5 to 55 mm; Roof profiles: 15 or 65 mm
Up to 1,0 W/m²K
Wall: 16-36 mm; Roof: 25-36 mm
10° to 45°

System technology

  • Modular system with a universally applicable profile and sealing system enables versatile applications

  • Flexible aluminium add-on construction made of profiles with a visible width of 42 mm or 50/52 mm for installation on any supporting substructure

  • Unique ventilation technology with continuous ventilation in roof and façade elements of any length

  • Available as a highly insulated and thermally separated version depending on project requirements

  • Integration of compatible photovoltaic modules possible

  • Depending on the design option, aluminium profile systems made from Hydro CIRCAL 75R – a sustainable aluminium alloy containing at least 75% post-consumer recycled aluminium

  • Time savings of up to 30% during processing and installation thanks to the modular system
